export ORACLE_HOME=/oracle/app/oracle/product/12.1.0.2/dbhome_1

$ORACLE_HOME/jdk/bin/java -jar /oracle/app/oracle/product/19.0.0.0/dbhome_1/rdbms/admin/preupgrade.jar


==================
PREUPGRADE SUMMARY
==================
  /oracle/app/oracle/product/12.1.0.2/dbhome_1/cfgtoollogs/TESTDB/preupgrade/preupgrade.log
  /oracle/app/oracle/product/12.1.0.2/dbhome_1/cfgtoollogs/TESTDB/preupgrade/preupgrade_fixups.sql
  /oracle/app/oracle/product/12.1.0.2/dbhome_1/cfgtoollogs/TESTDB/preupgrade/postupgrade_fixups.sql

Execute fixup scripts as indicated below:

Before upgrade:

Log into the database and execute the preupgrade fixups
@/oracle/app/oracle/product/12.1.0.2/dbhome_1/cfgtoollogs/TESTDB/preupgrade/preupgrade_fixups.sql

After the upgrade:

Log into the database and execute the postupgrade fixups
@/oracle/app/oracle/product/12.1.0.2/dbhome_1/cfgtoollogs/TESTDB/preupgrade/postupgrade_fixups.sql

Preupgrade complete: 2019-08-26T13:09:51

SQL> @/oracle/app/oracle/product/12.1.0.2/dbhome_1/cfgtoollogs/TESTDB/preupgrade/preupgrade_fixups.sql

Executing Oracle PRE-Upgrade Fixup Script

Auto-Generated by:       Oracle Preupgrade Script
                         Version: 19.0.0.0.0 Build: 1
Generated on:            2019-08-26 13:09:37

For Source Database:     TESTDB
Source Database Version: 12.1.0.2.0
For Upgrade to Version:  19.0.0.0.0

Preup                             Preupgrade
Action                            Issue Is
Number  Preupgrade Check Name     Remedied    Further DBA Action
------  ------------------------  ----------  --------------------------------
    1.  invalid_objects_exist     NO          Manual fixup recommended.
    2.  exclusive_mode_auth       NO          Manual fixup recommended.
    3.  case_insensitive_auth     NO          Manual fixup recommended.
    4.  underscore_events         NO          Informational only.
                                              Further action is optional.
    5.  dictionary_stats          YES         None.
    6.  parameter_deprecated      NO          Informational only.
                                              Further action is optional.
    7.  min_archive_dest_size     NO          Informational only.
                                              Further action is optional.
    8.  rman_recovery_version     NO          Informational only.
                                              Further action is optional.

The fixup scripts have been run and resolved what they can. However,
there are still issues originally identified by the preupgrade that
have not been remedied and are still present in the database.
Depending on the severity of the specific issue, and the nature of
the issue itself, that could mean that your database is not ready
for upgrade.  To resolve the outstanding issues, start by reviewing
the preupgrade_fixups.sql and searching it for the name of
the failed CHECK NAME or Preupgrade Action Number listed above.
There you will find the original corresponding diagnostic message
from the preupgrade which explains in more detail what still needs
to be done.

PL/SQL procedure successfully completed.

SQL> @$ORACLE_HOME/rdbms/admin/utlrp.sql


SQL> select count(*) from dba_objects where status='INVALID';

  COUNT(*)
----------
         0

set pagesize500
set linesize 100
select substr(comp_name,1,40) comp_name, status, substr(version,1,10) version from dba_registry order by comp_name;



COMP_NAME
----------------------------------------------------------------------------------------------------
STATUS      VERSION
----------- ----------------------------------------
JServer JAVA Virtual Machine
VALID       12.1.0.2.0

Oracle Database Catalog Views
VALID       12.1.0.2.0

Oracle Database Java Packages
VALID       12.1.0.2.0

Oracle Database Packages and Types
VALID       12.1.0.2.0

Oracle Multimedia
VALID       12.1.0.2.0

Oracle Text
VALID       12.1.0.2.0

Oracle Workspace Manager
VALID       12.1.0.2.0

Oracle XDK
VALID       12.1.0.2.0

Oracle XML Database
VALID       12.1.0.2.0

SQL> SELECT o.name FROM sys.obj$ o, sys.user$ u, sys.sum$ s WHERE o.type# = 42 AND bitand(s.mflags, 8) =8;

no rows selected

SQL> select * from v$timezone_file;

FILENAME                VERSION     CON_ID
-------------------- ---------- ----------
timezlrg_18.dat              18          0

SQL> SELECT * FROM v$backup WHERE status != 'NOT ACTIVE';

no rows selected

SQL> SELECT * FROM v$recover_file;

no rows selected

SQL> purge dba_recyclebin;

alter system set db_recovery_file_dest_size=20G scope=both;
alter system set db_recovery_file_dest='/dumparea/FRA/' scope=both;
alter database flashback on;

SQL> select comp_id,status from dba_registry;

COMP_ID                        STATUS
------------------------------ -----------
CATALOG                        VALID
CATPROC                        VALID
JAVAVM                         VALID
XML                            VALID
CATJAVA                        VALID
RAC                            OPTION OFF
XDB                            VALID
OWM                            VALID
CONTEXT                        VALID
ORDIM                          VALID

10 rows selected.

SQL> select * from v$timezone_file;

FILENAME                VERSION     CON_ID
-------------------- ---------- ----------
timezlrg_32.dat              32          0

cat sqlnet.ora

SQLNET.ALLOWED_LOGON_VERSION_SERVER=11

select * from v$restore_point;

drop restore point

alter system set compatible='19.0.0' scope=spfile;
shutdown immediate;
startup

SELECT name, value FROM v$parameter
         WHERE name = 'compatible';
